Using SharpNav with Unity

An article by mgear

Noticed this SharpNav repository (Advanced Pathfinding for C#) at https://github.com/Robmaister/SharpNav

Since new unity versions support .NET 4.6, this should work in unity too,
the sample script below runs, but not sure how to access the navmesh or navigation features..

Instructions:
– Download SharpNav https://github.com/Robmaister/SharpNav
– Open SharpNav-master\SharpNav-master\Source\SharpNav.sln in VisualStudio
– Right click SharpNav on the Solution Explorer, select Build *Note: this compiles with 4.5.1
– Copy ‘SharpNav.DLL ‘, ‘Newtonsoft.Json.dll’ and ‘YamlDotNet.dll’ files from SharpNav-master\SharpNav-master\Binaries\SharpNav\Debug\ folder into unity project, Plugins/ – folder
– In Unity project, select .NET 4.6 in the player settings *Need to restart unity after this
– Download example mesh and add to scene, from: https://github.com/Robmaister/SharpNav/blob/96ddd939f292a4f4e76b460c1f783cdf1e9bcf41/Source/SharpNav.Examples/nav_test.obj
– Attach script below into empty gameobject
– Drag example mesh into meshFilter field in the empty gameobject script
– Hit Play! (nothing really happens.. would have to access the navmesh, but you are on your own now..*please post comment if you get it working, i’d like to know also : )

**Note: here is older unity project for Recast/Detour library: https://github.com/unitycoder/rcdtcs

Source:

	using SharpNav;
	using SharpNav.Geometry;
	using System.Collections;
	using System.Collections.Generic;
	using UnityEngine;
	using Vector3 = UnityEngine.Vector3;

	public class SharpNavTest : MonoBehaviour
	{
	// assign your mesh here, try the example mesh provided in https://github.com/Robmaister/SharpNav/blob/96ddd939f292a4f4e76b460c1f783cdf1e9bcf41/Source/SharpNav.Examples/nav_test.obj
	public MeshFilter meshFilter;


	void Start()
	{
	// get mesh data
	var vertices = meshFilter.mesh.vertices;
	var indices = meshFilter.mesh.triangles;
	var triangleCount = meshFilter.mesh.triangles.Length;

	// convert into sharpnav Vector3 array
	SharpNav.Geometry.Vector3[] navVerts = new SharpNav.Geometry.Vector3[vertices.Length];
	for (int i = 0, length = vertices.Length; i < length; i++)
	{
	navVerts[i] = ToSharpVector(vertices[i]);
	}

	//prepare the geometry from your mesh data
	var tris = TriangleEnumerable.FromVector3(navVerts, 0, 1, vertices.Length / 3);

	// check bounds
	var bounds = tris.GetBoundingBox();
	Debug.DrawLine(ToUnityVector(bounds.Min.Xzy), ToUnityVector(bounds.Max.Xzy), Color.red, 99);

	//use the default generation settings
	var settings = NavMeshGenerationSettings.Default;
	settings.AgentHeight = 1.7f;
	settings.AgentRadius = 0.6f;

	//generate the mesh
	var navMesh = NavMesh.Generate(tris, settings);

	// TODO: now what???

	}


	// converts sharpnav vector3 to unity vector3
	Vector3 ToUnityVector(SharpNav.Geometry.Vector3 vector)
	{
	return new Vector3(vector.X, vector.Y, vector.Z);
	}

	// converts unity vector3 to sharpnav vector3
	SharpNav.Geometry.Vector3 ToSharpVector(Vector3 vector)
	{
	return new SharpNav.Geometry.Vector3(vector.x, vector.y, vector.z);
	}
	}
