Halton Sequence c#
Halton Sequence script to Unity c#. (image: Left side halton sequence, right side using Random.value).
Needed something to distribute objects evenly on given area.. this works for small amount of objects <200, but if add more, they start to form lines(?)
Converted from:
“Halton Sequence Test” by Sean Davies, licensed under Creative Commons Attribution-Share Alike 3.0 and GNU GPL license.
Work: http://openprocessing.org/visuals/?visualID= 1781
License: http://creativecommons.org/licenses/by-sa/3.0/ http://creativecommons.org/licenses/GPL/2.0/
Source c#:
// HaltonSequence.cs using UnityEngine; using System.Collections; // converted to unity c# by http://unitycoder.com/blog // original source: http://www.openprocessing.org/sketch/1920 public class HaltonSequence { public Vector3 m_CurrentPos = new Vector3(0.0f,0.0f,0.0f); long m_Base2 = 0; long m_Base3 = 0; long m_Base5 = 0; public long Increment() { float fOneOver3 = 1.0f/3.0f; float fOneOver5 = 1.0f/5.0f; long oldBase2 = m_Base2; m_Base2++; long diff = m_Base2 ^ oldBase2; float s = 0.5f; do { if ((oldBase2 & 1) == 1) m_CurrentPos.x -= s; else m_CurrentPos.x += s; s *= 0.5f; diff = diff >> 1; oldBase2 = oldBase2 >> 1; } while (diff > 0); long bitmask = 0x3; long bitadd = 0x1; s = fOneOver3; m_Base3++; while (true) { if ((m_Base3 & bitmask) == bitmask) { m_Base3 += bitadd; m_CurrentPos.y -= 2 * s; bitmask = bitmask << 2; bitadd = bitadd << 2; s *= fOneOver3; } else { m_CurrentPos.y += s; break; } }; bitmask = 0x7; bitadd = 0x3; long dmax = 0x5; s = fOneOver5; m_Base5++; while (true) { if ((m_Base5 & bitmask) == dmax) { m_Base5 += bitadd; m_CurrentPos.z -= 4 * s; bitmask = bitmask << 3; dmax = dmax << 3; bitadd = bitadd << 3; s *= fOneOver5; } else { m_CurrentPos.z += s; break; } }; return m_Base2; } public void Reset() { m_CurrentPos.x = 0.0f; m_CurrentPos.y = 0.0f; m_CurrentPos.z = 0.0f; m_Base2 = 0; m_Base3 = 0; m_Base5 = 0; } }
Source c# (for testing it)
// HaltonTest.cs using UnityEngine; using System.Collections; public class HaltonTest : MonoBehaviour { HaltonSequence positionsequence = new HaltonSequence(); void Start () { float size = 20.0f*2; positionsequence.Reset(); Vector3 position = Vector3.zero; int amount = 200; for(int i=0;i<amount;i++) { positionsequence.Increment(); //position.set(positionsequence.m_CurrentPos); //Debug.Log(positionsequence.m_CurrentPos); position = positionsequence.m_CurrentPos; //position.x -=0.5f; position.y = 0.0f; //position.z -=0.5f; position *= size; GameObject sphere = GameObject.CreatePrimitive(PrimitiveType.Sphere); sphere.transform.position = position; } // random for(int i=0;i<amount;i++) { GameObject sphere = GameObject.CreatePrimitive(PrimitiveType.Sphere); sphere.transform.position = new Vector3(Random.value*size,0,Random.value*size) + new Vector3(size+10,0,0); } } }
Related Posts
11 Comments + Add Comment
Leave a comment
Recent posts
- [GreaseMonkey] Unity Forum Fixer
- UnityHub: Make Hub application background Translucent
- Customize SpriteShapeRenderer quality (but has issues)
- Editor tool: Copy selected gameobject’s names into clipboard as rows (for Excel)
- Editor tool: Replace string in selected gameobject’s names
- UnityHub: Enable built-in Login Dialog (no more browser login/logout issues!)
- Use TikTok-TTS in Unity (with WebRequest)
- Create Scene Thumbnail Image using OnSceneSaved & OnPreviewGUI
- webgl+javascript TTS
- Using Moonsharp (LUA) + Unity Webgl
- Using 3D gameobject prefabs with Unity Tilemap + NavMesh Surface
- Custom Unity Hub Project Template Preview Image/Video (using HTML+CSS in package description)
Recent Comments
- Vector3 maths for dummies! on
- UnityHub: Make Hub application background Translucent on
- UnityHub: Make Hub application background Translucent on
- Install Android SDK+JDK+NDK for Unity (without AndroidStudio or Unity Hub) on
- Install Android SDK+JDK+NDK for Unity (without AndroidStudio or Unity Hub) on
- [Asset Store] Point Cloud Viewer & Tools on
- [Asset Store] Point Cloud Viewer & Tools on
- ffmpeg stream raw video into Unity Texture2D on
“Blue noise sample pattern”
http://www.cs.ubc.ca/~rbridson/docs/bridson-siggraph07-poissondisk.pdf
Distributing GameObjects evenly on a sphere:
http://forum.unity3d.com/threads/215479-Distributing-empty-GameObjects-evenly-on-a-sphere
Fast Uniform Poisson-Disk Sampling in C#:
http://theinstructionlimit.com/fast-uniform-poisson-disk-sampling-in-c
grass distribution:
http://mollyrocket.com/casey/stream_0015.html
poisson disk sampling: (unity)
http://gregschlom.com/devlog/2014/06/29/Poisson-disc-sampling-Unity.html
Object Placement with poisson disk sampling:
http://devmag.org.za/2009/05/03/poisson-disk-sampling/
random distribution on image density mask:
http://forum.unity3d.com/threads/help-with-random-distribution-script.277194/#post-1831558
distributing points on sphere (electrostatic repulsion)
http://nodename.com/blog/2008/09/19/distributing-points-on-the-sphere/
Math for Game Developers – Procedural Generation (Uniform Sampling of a Circle)
Math for Game Developers – Procedural Generation (White and Blue Noise)
Poisson-Disc (js)
http://bl.ocks.org/mbostock/19168c663618b7f07158
others : http://bl.ocks.org/mbostock
New: R2 Sequence
http://extremelearning.com.au/unreasonable-effectiveness-of-quasirandom-sequences/
